• Civil Engineering
• Mines, quarries, coal ore and slurries
• Sewage Treatment plants
• General pumping purposes

• Water temperature : Up to 45°C
• Power Supply : Three phase 380-420V, 50Hz
• Power :1.5 kW / 2.0 HP
• Insulation Class: F
• Protection Class : IPX8 / IP68
• Max Head : 22 m
• Max Flow : 30 M3/HR
• Outlet : 2"
• Speed : 2900 RPM
• Liquid pH Value : 6.5 - 8.5
• Cable length : 8 m




• Compact design, high performance and exceptional durability for handling abrasive liquid, widely used in general construction and civil engineering.
• The body of motor and pump is made of rigid cast iron or stainless steel for long-lasting durability.
• Greatly increased maximum submersion depth due to mechanical seal resistance to high pressure (0.5Mpa)
• Semi-open impeller made of SS 304 match with diffuser plate (SS304) achieves superior durability.
• Effective motor cooling due to discharge channel cast iron as part of the motor housing. Space economy by a top outlet.
• Hermetically sealed motor equip build-in thermal protection. The protector in the motor can automatically cut off the power when it overheats or over current.



  Model	Power		Outlet	Q	M3/H	0	10	20	30
  	KW	HP			LPM	0	167	333	500
  PDP1.5-2	1.5	2.0	2”	Head (meters)		22	17	12	6
