• For mining, buildings, factory & industrial applications.
• For water supply from wells, tanks and reservoirs.
• For garden use and agricultural irrigation.

• Head: 94 Mtr
• Flow: 467 LPM
• Power: 5.5 KW / 7.5 HP
• Insulation Class: F
• Protection Class: IP68
• Outlet : G3"
• Cable length: 15m
• Water temperature up to 40°C
• Power supply: 380-420V, Three Phase 50 Hz

  Function and feature:
  • The hydraulic part under the motor and motor cooled by the pumped water for safe operation, also with the pump is only partially immersed.
  • An electric motor cooled by the pumped liquid for a long time.



  Model	Power		Outlet	Q	M3/H	0	5	10	15	20	25	28
  	KW	HP			LPM	0	82	167	250	333	417	467
  PQXNSP-7.5	5.5	7.5	G3"	Head (meters)		94	91	85	72	52	30	12
