Application:

• Scum pumping at the wastewater treatment plant
• Municipal projects
• Industrial packaged pump station
• Home and domestic application (Special for the kitchen)
• Pumping agricultural manure (dairy, hog, and poultry)

• Max Flow: 417 LPM
• Max Head: 12 m
• Speed: 3450 rpm
• Power: 0.75 kW / 1.0 HP
• Outlet: 2"
• Max Liquid Temperature: Up to 40°C
• Max Ambient Temperature Up to 40°C
• Insulation Class: F
• Protection class: IPX8 / IP68
• pH: 6.5-8.5





  Feature & Benefits :

  A non-clogging double vane impeller can pump a large solid cove's full range of head.
  Chrome-plated shaft ensures high corrosion resistance and wear resistance.
  Designed for pumping sewage, wastewater, rainwater, and living water containing solid grains, various fabrics, sludge,e and solid.



  Installation and Use :

  This model of pump is characterized by high heads, compact size, light weight, and convenient use, and is widely used in high-position water delivery, flushing, and places such as construction sites. The float switch can automatically turn on and off with the change of the water level. The protection in the motor can automatically cut off the power when it overheats or experiences an overcurrent.

Pump Selection Chart :

Pump Performance Chart :
