Application:

Municipal Projects
Industrial and Residential buildings
Mining
Civil Engineering
Pumping Sewage from domestic, hotel,  school and public buildings

• Max Flow: 417 LPM
• Max Head: 12 m
• Speed: 3450 rpm
• Power: 0.75 kW / 1.0 HP
• Voltage: 220-240V, 60Hz

• Outlet: 2"
• Max Liquid Temperature: Up to 40°C
• Max Ambient Temperature Up to 40°C
• Insulation Class: F
• Protection class: IPX8 / IP68
• Liquid pH Value: 6.5-8.5





  Feature & Benefits :

  Non-clogging double vane impeller can pump large solid cove full range of head.
  Chrome plated shaft ensure high corrosion resistant and wear resistance.
  Designed for pumping sewage, waste water, rainwater and living water containing solid grains, various fabric, sludge and solid.



  Installation and Use :

  This model of pump is characterized by high heads, compact size, light weight, and convenient use, and is widely used in high-position water delivery, flushing, and places such as construction sites. The float switch can automatically turn on and off with the change of the water level. The protection in the motor can automatically cut off the power when it overheats or experiences an overcurrent.

Pump Performance Chart :
