• For water supply from open wells, tanks, or reservoirs.
• For domestic use, Civil and industrial applications.
• For garden and irrigation, the Utilization of rainwater



• Max Head: 80 Mtr
• Max Flow: 83.2 LPM
• Power: 1.1 KW / 1.5 HP
• Outlet: 1.25"
• Speed: 3450 RPM
• Insulation Class: F
• Protection Class: IPX8
• Water temperature up to 40°C
• Minimum Internal diameter of well: 132mm
• Liquid pH Value: 6-8
• Power Supply: Single Phase 220-240V, 60Hz



• Single phase with built-in capacitor and thermal protector on control box required Three phase with built-in thermal protector.
• Hermetically sealed motor equip build-in thermal protection. The protector in the motor can automatically cut off the power when it overheats or over current.
• Close coupled multi-stage submersible pump in chrome –nickel stainless steel.
• Hydraulic part under the motor and motor cooled by the pumped water for safe operation also with the pump only partially immersed.
• Double shaft seal with interposed oil chamber.
• The suction strainer prevents the entrance of solids with diameter bigger than 2 mm.



  Model	Power		Q	M3/H	0	1	1.5	2	3	3.5	4.5	5
  	KW	HP		LPM	0	17	25	33	50	58	75	83.2
  P205	1.1	1.5	Head (m)		80	75	71	67	57	50	33	24
