Applications:
- For water supply from open wells, tanks or reservoirs.
- For domestic use, Civil and industrial applications.
- For garden and irrigation, Utilization of rain water.
Specification:
- Power : 1.1 KW / 1.5 HP
- Max Head : 66 meter
- Max Flow : 133 LPM
- Outlet : 1.25"
- Water temperature : up to 35°C
- Minimum internal diameter of well: Ø132mm.
- Insulation Class : F
- Protection Class : IP 68
- Power Supply : single phase 220-240V, 50Hz
Function and feature:
- Single phase with built-in capacitor and thermal protector on control box required Three phase with built-in thermal protector.
- Hermetically sealed motor equip build-in thermal protection. The protector in the motor can automatically cut off the power when it overheats or over current.
- Close coupled multi-stage submersible pump in chrome –nickel stainless steel.
- Hydraulic part under the motor and motor cooled by the pumped water for safe operation also with the pump only partially immersed.
- Double shaft seal with interposed oil chamber.
- The suction strainer prevents the entrance of solids with diameter bigger than 2 mm.
Model
Power
Outlet
Q
M3/H
0
2.5
3
3.5
4
4.5 5 6 7 8 KW
HP
LPM
0
42
50
58
67
75 83 100 117 133 P406
1.1
1.5
1.25"
Head (meters)
66
60
58
56
54
51.5 49 42 34 20.5
