• For water supply from open wells, tanks, or reservoirs.
• For domestic use, Civil and industrial applications.
• For garden and irrigation, the Utilization of rainwater



• Max Head: 76 Mtr
• Max Flow: 750 LPM
• Power: 7.5 KW / 10 HP
• Outlet: 3"
• Speed: 3450 RPM
• Insulation Class: F
• Protection Class: IP 68
• Liquid pH value: 6-8
• Water temperature up to 40°C
• Minimum Internal diameter of well: 200mm
• Power supply: Three Phase, 380-420V, 60 Hz



• Hydraulic part under the motor and motor cooled by the pumped water for safe operation also with the pump only partially immersed.
• Electric motor cooled by pumped liquid for long time.



  Model	Power		Q	M3/H	0	6	12	18	24	30	40	45
  	KW	HP		LPM	0	100	200	300	400	500	667	750
  PQXNSP-10	7.5	10	Head (m)		76	74	71	68	62	50	28	15
