Application:

• Domestic Water Supply
• Lawn Sprinkler, villas
• Automobile Washing
• Gardens Water Supply
• Pressure Boosting in Various Fields, small air conditioner system or supporting equipment etc.



Specifications:

• Max Head : 34 meter
• Max Flow : 170 LPM
• Speed : 2900 rpm
• Power : 1.1Kw
• Inlet/Outlet : 1.25" X 1"
• Liquid Temperature : up to 90°C
• Insulation Class : F/B
• Protection Class : IP54
• Voltage : 220-240V, 50Hz
• Thermal Protection : In built (Single phase)
• Max Suction : up to 8m




Installation and use :
Suitable for clean water that does not contain abrasive particles and liquids that are not chemically aggressive towards the materials from which the pump is made.

Thanks for it's reliability, the fact that these pumps are easy to use and very economical, these are ideal for domestic and civil use and in particular for distributing water in combination with small and medium pressure sets, irrigation of gardens and allotment. The pump should be installed in an enclosed environment, or at least sheltered from inclement weather.



Model	Power		Inlet /Outlet	Q	M3/H	0	0.6	1.2	1.8	2.4	3	3.6	4.2	4.8	5.4	6	6.6	7.2	7.8	8.4	9	9.6	10.2
	KW	HP			LPM	0	10	20	30	40	50	60	70	80	90	100	110	120	130	140	150	160	170
PCP15	1.1	1.5	1.25”x1”	Head (meters)		34	33	32	31	30	29	28	27	26	25	24	22.5	21	19	19	14	10.5	6
