Applications:

• For water supply from open wells, tanks or reservoirs.
• For domestic use, Civil and industrial applications.
• For garden and irrigation, Utilization of rain water.



Specification:

• Power : 1.1 KW / 1.5 HP
• Max Head : 80 M
• Max Flow : 83.2 LPM
• Outlet : 1.25"
• Water temperature : up to 35°C
• Minimum internal diameter of well: Ø132mm.
• Insulation Class : F
• Protection Class : IP 68
• Power Supply : single phase 220-240V, 50Hz
• Pump with cable and starter




Function and feature:

• Single phase with built-in capacitor and thermal protector on control box required Three phase with built-in thermal protector.
• Hermetically sealed motor equip build-in thermal protection. The protector in the motor can automatically cut off the power when it overheats or over current.
• Close coupled multi-stage submersible pump in chrome –nickel stainless steel.
• Hydraulic part under the motor and motor cooled by the pumped water for safe operation also with the pump only partially immersed.
• Double shaft seal with interposed oil chamber.
• The suction strainer prevents the entrance of solids with diameter bigger than 2 mm.




  Model	Power		Outlet	Q	M3/H	0	1	1.5	2	2.5	3	3.5	4	4.5
  	KW	HP			LPM	0	17	25	33	42	50	58	67	75
  P207	1.1	1.5	1.25"	Head (meters)		80	76	71.5	66	60	52.5	46	37	24

   For more information download the Catalog
