Applications:
Water supply systems
Pressure boiler feeding
Pure water treating systems
Pharmaceutical and food processing
Refining and chemical industries
Washing and sprinkling
RO Plants

Specifications :
Max Flow: 180 LPM
Max Head: 35 meters
Power: 1.5 kW / 2.0 HP
Inlet / Outlet: 1.25″x1″
Speed: 3500 RPM
Voltage: 380-420V, 60Hz
Max Suction: Up to 8m
Max. Working Pressure: 8 Bar
Liquid Temperature: up to 90°C
Ambient Temperature range: up to 40°C
Liquid pH Value: 4 - 10
Insulation Class: F
Protection Class: IPX4
Altitude : < 1000m

Features :
This series is suitable for transporting clean media that are non-aggressive to stainless steel 316.
Compact & nice appearance while being efficient and low in voice.
Our pumps have a reliable seal, which results in the case of maintenance & use.

Pump Performance Chart :
