Application:

• Civil agricultural, Industries, & General plant use
• Hot and cold water circulation
• Spray or flowing irrigation
• Autoclave feed
• High-pressure system
• Residential and commercial chiller plant

• Max Flow: 90 M3/HR
• Max Head: 65 m
• Speed: 3500 rpm
• Power: 15 kW / 20.0 HP
• Inlet/Outlet: 3"x3"
• Max Liquid Temperature: Up to 105°C
• Max Ambient Temperature Up to 40°C
• Insulation Class: F
• Altitude : <1000m
• 100% Copper Winding
• Protection class: IPX4 / IP54
• Liquid pH Value: 6-8


  Installation and Use:-
  These pumps are ideal for pumping clean water and other chemically and mechanically non-aggressive liquids. These system can be installed in any position, provide the inlet opening faces upwards, and, thanks to their Special design-which allows back pull out of the motor and the rotary parts Of the pump and subsequent re-assembly without having to remove the pump Body and the pipes connected to it – can be easily and conveniently used for a wide variety of applications in civil, agricultural, industrial or general plant uses. Water supply, spray or flowing irrigation, autoclave feed, high pressure system heating, conditioning and any other service requiring transfer of clean liquids.



Pump Performance Chart :
