Applications:
Domestic water supply
Lawn Sprinkler, villas
Automobile washing
Gardens water supply
Pressure boosting in fields, small air conditioner systems, or supporting equipment, etc

Specifications :
Max Flow: 1200 LPM
Max Head: 19 meters
Power: 2.2 KW / 3.0 HP
Inlet /Outlet: 3″x3″
Speed: 3500 RPM
Voltage: 380-420V, 60Hz
Liquid Temperature: up to 90°C
Liquid pH Value: 6 - 8
Insulation Class: F
Protection Class: IPX4
Altitude : < 1000m

Installation and use :
Suitable for clean water that does not contain abrasive particles and liquids that are not chemically aggressive towards the materials from which the pump is made.
Thanks to its reliability, the fact that these pumps are easy to use and very economical, these are ideal for domestic and civil use, and in particular for distributing water in combination with small and medium pressure sets, irrigation of gardens and allotments. The pump should be installed in an enclosed environment, or at least sheltered from inclement weather.

Pump Performance Chart :

Model	Power		Inlet /Outlet	Q	M3/H	0	6	18	30	42	54	66	72
	KW	HP			LPM	0	100	300	500	700	900	1100	1200
PCP30T	2.2	3.0	3”x3”	Head (meters)		19	18.5	17.5	16	14	11.5	8	6
