Applications:

• Irrigation in horticulture and agriculture
• Drip and sprinkler irrigation
• Pressure boosting application
• Water treatment
• Civil and industrial application
• Domestic water supply

Specifications:

• Water temperature: Up to 45°C
• Minimum internal diameter of well: 4” Ø100mm.
• Power: 2.2 kW to 4.0 kW  (Three Phase)
                    0.37 kW to 2.2 kW (Single Phase)
• Power Supply: Three-phase 380V-415V, 50 Hz.
                                     Single Phase 220V-240V, 50Hz
• Speed : 2900 RPM
• Insulation Class: F
• Protection Class: IP 68
• Max No. of starts per hour: 25
• Rotating: CCW and CW.
• Standard motor with poly wrapping insulated winding
• Ambient temp. of 30°C with a minimum. Cooling flow: 4.0Kw - 15kw, V=0.2m/s
• Installation position: Vertical/Horizontal
• Duty: S1

Product Feature:

• Easily rewindable (wet wound) induction motor with PVC/ Poly wrapping insulated winding.
• Water-lubricated radial and thrust bearing.
• Corrosion-resistant stainless steel stator jacket.
• Non-contaminating water filling design.
• High efficiency electrical design for low operation cost.
• Tropical zed design. (Lower winding temperature)
• 4" NEMA flange with M8 stud.
• Cable material according to the drinking water regulation.
• All motors are prefilled and 100% tested.
• Sand slinger for high performance in sand.





  *Technical Data: Three-phase 380V-415V, 50 Hz.
                                       Single Phase 220V-240V, 50Hz




  MODEL	MOTOR  POWER		MAX. FULL LOAD (A)	PHASE	STARTING CURRENT (A)	FULL LOAD		METHOD OF START	MAX. DOWN THRUST LOAD (N)	TORQUE (Nm)	STARTING TORQUE (Nm)
  	kW	HP				Eff.%	Power Factor
  PSMP100- 0.5-SP	0.37	0.5	5	1	16	39	0.89	CSCR	3000	1.2	2.0
  PSMP100- 0.75-SP	0.55	0.75	6	1	21	52	0.90	CSCR	3000	1.8	2.9
  PSMP100- 1.0-SP	0.75	1.0	7.5	1	26	54	0.90	CSCR	3000	2.5	4.1
  PSMP100- 1.5-SP	1.1	1.5	10	1	40	57	0.95	CSCR	3000	3.7	6.1
  PSMP100- 2.0-SP	1.5	2.0	12	1	48	60	0.95	CSCR	3000	4.9	8.3
  PSMP100- 3.0-SP	2.2	3.0	19	1	66	62	0.95	CSCR	6500	7.4	13.3
  PSMP100- 3.0	2.2	3.0	7	3	23	69	0.78	D.O.L	6500	7.0	15
  PSMP100- 4.0	3.0	4.0	9	3	31	74	0.73	D.O.L	6500	10	22
  PSMP100- 5.5	4.0	5.5	10	3	43	75	0.80	D.O.L	6500	14	31
