Application

• Ground water supply to waterworks
• Irrigation in horticulture and agriculture
• Ground water lowering
• Pressure boosting
• Civil and industrial work
• Fire fighting applications



Specification :

• Power : 1.1 Kw - 5.5 Kw / 1.5 HP - 7.5 HP
• Max Flow : up to 200 LPM
• Head : up to 202 m
• Speed : 2900 RPM
• Water temperature : up to 45°C
• Minimum internal diameter of well : 4” Ø100mm.
• The solids in the water is less than 0.02% (heavy proportion)
• Liquid pH Value: 6.5 – 8.0



  Installation and use :

  • Pump sizes for connecting to motor according to NEMA standards.
  • Delivery casing with built -in non return valve for stop coming back water.
  • Manufactured From corrosion resistant materials for long life impellers-PPO, diffuser-PC, and Delivery casing are SS304.
  • Specific impeller material selection ensures optimal performance in sandy bores.
  • This type models feature independently floating centrifugal impellers to provide easy starting and long life automatically adjusting to match pumping conditions for various application.
  • Heavy duty stainless steel Inner and outer shell providing protection and accurate alignment of internal components.
  • High quality shaft bearings providing low friction and high wear resistance.
  • Strong stainless steel drive shaft ensures positive impeller drive and longer life.



    MODEL	POWER		OUTLET	HEIGHT		Q	M3H	0	3.0	4.8	5.4	6.0	7.2	8.4	9.6	10.8	12.0
    	KW	HP		H	L		LPM	0	50	80	90	100	120	140	160	180	200
    SSFP12-1.1-68	1.1	1.5	2"	364	806	HEAD      (m)		38	36	35	34	33	31	28	24	19	14
    SSFP12-1.5-810	1.5	2.0		426	898			52	50	47	45.5	44	41	37	31	25	18
    SSFP12-2.2-1315	2.2	3.0		581	1098			82	78	75	73	71	66	59	50	40	30
    SSFP12-4-2325	4.0	5.5		929	1531			148	140	134	131	127	118	108	95	79	60
    SSFP12-5.5-3237	5.5	7.5		1208	1954			202	190	182	178	172	160	143	125	105	80
