Application:

Municipal Projects
Industrial and Residential buildings
Mining
Civil Engineering
Pumping Sewage from domestic, hotel,  school and public buildings

Specifications :

Max Flow: 1349 LPM
Max Head: 24 Meter
Power: 4 KW / 5.5HP
Speed: 2900 RPM
Water temperature: Up to 40˚C
pH: 6.5 - 8.5
Ambient temperature: up to 40˚C
Insulation Class: F
Protection Class: IP 68
Duty: S1
Voltage : 380-420V, 50Hz

Feature & Benefits :
Non-clogging double vane impeller can pump a large solid cove full range of head.
Chrome-plated shaft ensures high corrosion resistance and wear resistance.
Designed for pumping sewage, wastewater, rainwater, and living water containing solid grains, various fabrics, sludge, and solid.

Installation and Use :

This model of pump is characterized by high heads, compact size, light weight, and convenient use, and is widely used in high-position water delivery, flushing, and places as construction sites. The float switch can automatically turn on and off with the change of the water level. The protection in the motor can automatically cut off the power when it overheats or overcurrent.
