Applications:

• Irrigation in horticulture and agriculture
• Drip and sprinkler irrigation
• Pressure boosting application
• Water treatment
• Civil and industrial application
• Domestic water supply

Specifications:

• Water temperature: Up to 45°C
• Minimum internal diameter of well: 6” Ø150mm.
• Power: 4 kW to 45 kW  (7.5 HP to 60 HP)
• Power Supply: Three-phase 220V/380V, 60 Hz.
• Insulation Class: B
• Protection Class: IP 68
• Max No. of starts per hour: 25
• Speed: 3450 RPM
• Standard motor with poly wrapping insulated winding
• Ambient temp. of 30°C with a min. Cooling flow: 4.0 kW -15 kW, V=0.2m/s
                                                                                                              18.5 kW - 45 kW, v=0.5m/s
• Installation position: Vertical/Horizontal
• Duty: S1

Product Feature:

• 6" NEMA flange with M12 Stud.
• Easily rewindable (wet wound) induction motor with PVC/ Poly wrapping insulated winding.
• Water lubricated radial and thrust bearing, and high capacity Kingsbury type thrust bearing for 100%.
• Corrosion-resistant stainless steel stator jacket.
• Non-contaminating water filling design.
• High efficiency electrical design for low operation cost.
• Tropical zed design. (Lower winding temperature)
• Cable material according to the drinking water regulation.
• All motors are prefilled and 100% tested.
• Sand slinger for high performance in sand.



  *For more information, please download the catalog
