Applications:

• Irrigation in horticulture and agriculture
• Drip and sprinkler irrigation
• Pressure boosting application
• Water treatment
• Civil and industrial application
• Domestic water supply

Specifications:

• Water temperature: Up to 45°C
• Minimum internal diameter of well: 6” Ø150mm.
• Power: 4.0 kW to 45 kW  (5.5 HP to 60 HP)
• Power Supply: Three-phase 380V-415V ±10%, 50 Hz.
• Insulation Class: F
• Protection Class: IP 68
• Max No. of starts per hour: 25
• Speed: 2900 RPM
• Standard motor with poly wrapping, insulated winding
• Ambient temp. of 30°C with a minimum. Cooling
• Installation position: Vertical/Horizontal
• Duty: S1

Product Feature:
Easily rewindable (wet wound) induction motor with PVC/ Poly wrapping insulated winding.
Water-lubricated radial and thrust bearing.
Corrosion-resistant stainless steel stator jacket.
Non-contaminating water filling design.
High efficiency electrical design for low operation cost.
Tropical zed design. (Lower winding temperature)
6" NEMA flange with M12 stud.
Cable material according to the drinking water regulation.
All motors are prefilled and 100% tested.
Sand slinger for high performance in sand.

• Technical Data :  380V - 415V, 50 Hz, 2900 RPM



  MODEL	MOTOR   POWER		MAX. FULL LOAD (A)	STARTING     CURRENT        (A)	FULL LOAD		METHOD OF START	MAX.  DOWN THRUST LOAD (N)	TORQUE         (Nm)	STARTING TORQUE         (Nm)
  	kW	HP			Eff.%	Power Factor
  PSMC150-     5.5	4.0	5.5	10.5	43	76	0.70	D.O.L	15500	14	20
  PSMC150-      7.5	5.5	7.5	13	58	78	0.77	D.O.L	15500	18	24
  PSMC150-       10	7.5	10	16.5	72	82	0.75	D.O.L / S.D	15500	25	27
  PSMC150-       12.5	9.3	12.5	21	84	82	0.79	D.O.L / S.D	15500	31	35
  PSMC150-        15	11	15	24	103	83	0.80	D.O.L / S.D	15500	37	43
  PSMC150-       17.5	13	17.5	29	118	83	0.80	D.O.L / S.D	15500	43	51
  PSMC150-       20	15	20	33	148	83	0.81	D.O.L / S.D	15500	49	62
  PSMC150-        25	18.5	25	42	188	83	0.81	D.O.L / S.D	15500	61	98
  PSMC150-        30	22	30	49	225	83	0.81	D.O.L / S.D	15500	74	118
  PSMC150-        35	26	35	56	270	83	0.82	D.O.L / SD	27500	86	138
  PSMC150-        40	30	40	67	355	83	0.82	D.O.L / SD	27500	98	196
  PSMC150-        50	37	50	80	421	82	0.83	D.O.L / SD	27500	123	245
  PSMC150-        60	45	60	93	465	82	0.83	D.O.L / SD	27500	150	396




  *For More information, please download the catalog
