Applications:

• Irrigation in horticulture and agriculture
• Drip and sprinkler irrigation
• Pressure boosting application
• Water treatment
• Civil and industrial application
• Domestic water supply



Specifications:

• Water temperature : Up to 45°C
• Minimum internal diameter of well: 6” Ø150mm.
• Power : 4.0 kW to 22 kW  (5.5 HP to 30 HP)
• Power Supply: Three phase 380V-415V ±10%, 50 Hz.
• Insulation Class: F
• Protection Class : IP 68
• Max No. of starts per hour: 25
• Rotating: CCW and CW.
• Standard motor with poly wrapping insulated winding
• Speed : 2900 RPM
• Installation position : Vertical/Horizontal
• Duty: S1

Product Feature :

• Easily rewindable (wet wound) induction motor with PVC/ Poly wrapping insulated winding.
• Water lubricated radial and thrust bearing.
• Corrosion resistance stainless steel stator jacket.
• Non-contaminating water filling design.
• High efficiency electrical design for low operation cost.
• Tropical zed design. (Lower winding temperature)
• 6" NEMA flange with M12 stud.
• Cable material according to drinking water regulation.
• All motors prefilled and 100% tested.
• Sand slinger for high performance in sand.


  Technical Data :  380V - 415V, 50 Hz, 2900 RPM



  MODEL	MOTOR   POWER		MAX. FULL LOAD (A)	STARTING     CURRENT        (A)	FULL LOAD		METHOD OF START	MAX.  DOWN THRUST LOAD (N)	TORQUE         (Nm)	STARTING TORQUE         (Nm)
  	kW	HP			Eff.%	Power Factor
  PSMP150-     5.5	4.0	5.5	10.5	43	76	0.70	D.O.L	15500	14	20
  PSMP150-      7.5	5.5	7.5	13	58	78	0.77	D.O.L	15500	18	24
  PSMP150-       10	7.5	10	16.5	72	82	0.75	D.O.L / S.D	15500	25	27
  PSMP150-       12.5	9.3	12.5	21	84	82	0.79	D.O.L / S.D	15500	31	35
  PSMP150-        15	11	15	24	103	83	0.80	D.O.L / S.D	15500	37	43
  PSMP150-       17.5	13	17.5	29	118	83	0.80	D.O.L / S.D	15500	43	51
  PSMP150-       20	15	20	33	148	83	0.81	D.O.L / S.D	15500	49	62
  PSMP150-        25	18.5	25	42	188	83	0.81	D.O.L / S.D	15500	61	98
  PSMP150-        30	22	30	49	225	83	0.81	D.O.L / S.D	15500	74	118



  *For More information, please download the catalog
