Applications:-
Hot & cold booster pump
Shallow well, garden irrigation
Smart domestic installation
Pressure boiler feeding for washing
Pressurization of industrial plants
Small autoclaves
Transfer of liquids

Specifications:-

• Max Flow :- 50 LPM
• Max Head :- 65m
• Speed :- 2900 RPM
• Power :- 0.75 Kw / 1.0 HP
• Max Suction :- Up to 8m (Self priming)
• Protection  Class :- IPX4
• Insulation Class :- F
• Liquid Temperature up to 90°C
• Ambient Temperature Up to 40°C
• Max Working Pressure 8 Bar
• Voltage :- 220-240V, 50Hz

  Features :
  • Suitable for use with clean water, or non-aggressive liquids only, without sand or other solid impurities.
  • 3-second time delay of pump start after plugging into the socket to avoid potential danger caused by electric sparks
  • Automatic 10-second operation every 72 hours for anti-block protection in case of no use for long time
  • According the feedback from low sensor pressure Switch to control start, stop and dry-running protection Etc.



  Installation and Use:-

  PRAKASH as the professional manufacturer, we would like to provide you hot and cold-water booster pump. And we will offer you the best after-sale service and timely delivery. PACP series hot and cold-water booster pump belongs to the single-phase self-priming peripheral pump category, is a best seller pump in the global market. It is our patent design pump, attractive appearance, compact and very silent. The pump is assembled with very resistant and durable materials which is able to guarantee a very high solidity and the almost total absence of wear over time. Pumps should be installed in a covered area, protected against the weather



Model	Power		Inlet /Outlet	Q	M3/H	0	0.6	1.2	1.8	2.1	2.4	3
	KW	HP			LPM	0	10	20	30	35	40	50
PACP10	0.75	1.0	1”x1”	Head (meters)		65	52	38	26	21	17	10
