Application:

Municipal projects, mining, and civil engineering.
Industrial & residential buildings
Equipment for garden, aquarium, landscape waterfall, water drainage, and filtration

Specifications :

Max Flow: 1920 LPM
Max Head: 19 Meters
Power: 4.0 KW / 5.5 HP
Speed: 2900 RPM
Water temperature: Up to 45˚C
pH: 4 - 10
Insulation Class: F
Voltage: Three-phase 380-420v, 50Hz

Feature & Benefits :
A non-clogging double vane impeller can pump a large solid cove's full range of head.
Water contact parts are all stainless steel, with no rust
Designed for pumping sewage, wastewater, rainwater, and living water containing solid grains, various fabrics, sludge, and solids

Installation and Use:

This model of pump is characterized by high heads, compact size, light weight, and convenient use, and is widely used in high-position water delivery, flushing, and places such as construction sites. The float switch can automatically turn on and off with the change of the water level. The protection in the motor can automatically cut off the power when it overheats or overcurrent.
